Very Narrow Aisle Pallet Racking

IN Pallet Racking
portfolio
portfolio
About Product

Basic Info

  Name   VNA Pallet Racking   Model No.   IPR06
  Capacity   Up to 3000kg/Level   Material   Q235 or Q345 High Grade Steel
  Certificate   TUV, CE, ISO9000   Design Standards   Meet FEM, AS4084
  Finish   Powder Coating or Galvanized
  Est. Cost   USD$40/Pallet Location   Price Validation  Dec 2018
  Main Components   Frame (Upright, Bracing, foot plate), Beam, Frame Tie, Guide Rails, and accessories included
  Optional   Upright Protector, Frame Protector, etc.
  Color   Standard color – Blue RAL5015, Orange RAL2004, Orange RAL2008, Yellow RAL1003, Grey RAL7047, Dark Grey RAL7011, Green RAL6001. Customized color available upon providing RAL number.
  Packaging   Knockdown, well packed with plywood, plastic/steel strip, plastic film, cardboard box, plywood box.
  Shipping Port   Nanjing / Shanghai, China
  Payment Term   40% as down payment, balance before delivery
  MOQ   No Requirement
  Lead Time   Standard 2-3 weeks
  Warranty   1 year
 –
Information needed if you want our designs and pricing:
1, Pallet Size and fork entry side
2, Pallet Weight and Height (loads included)
3, Storage Area measurements or Warehouse drawings
4, Expected storage capacity if you have
5, other details such as pallet flow frequency, forklift type, functional storage areas, etc.


Keywords: VNA Pallet Racking, Push Back Racking System, VNA Storage Racking, VNA Metal Racking, VNA Warehouse Racking, Racking Manufacturer in China, Industrial Racking System;

VNA (Very narrow aisle) Pallet Racking is one type of standard pallet racking. Three-way forklift is used in this kind of racking system. Compared with standard pallet racking, the width of aisle of VNA Pallet Racking is much smaller. Warehouse space utilization can be increased by about 20%. VNA pallet racking is suitable for the goods which are many types, large quantity, heavy weight and fast transportation.

Technical Specifications:
– Surface process is powder coating
– The width of aisle is between 1.6m and 2.0m
– The racking’s height can be more than 10 meters.
– Guide rails are installed at both sides of the aisle for the three-way forklift running.
– Limited by the forklift, load capacity is no more than 1500kg/pallet
